Slim Section Bearings
2. Product structure: deep groove ball bearings, four-point contact ball bearings, crossed roller bearings, angular contact ball bearings
3. Size Range: Inner Bore Diameter: From approximately 50 mm to over 2000 mm
Cross-Section Height: Ranges from 20 mm to 100 mm
4. Material: Ring Material: High-strength 50Mn or 42CrMo alloy steel
Rolling Elements: High-precision, high-hardness GCr15 bearing steel balls
Seal Strip: Oil-resistant and wear-resistant nitrile rubber (NBR) seals
5. Applications: Industrial robots, medical equipment, aerospace, precision instruments, new energy, and automation
Slim Section Bearings: Space-Saving Precision Solutions for Modern Industry
When space and weight matter most in your precision applications, Slim Section Bearings deliver the perfect solution. These inventive orientation highlight an ultra-thin cross-section plan that maximizes execution whereas minimizing space prerequisites. Not at all like routine orientation, our items keep up extraordinary stack capacity in spite of their compact profile. At Luoyang Heng Guan Bearing Innovation Co.,Ltd, we design these specialized orientation to meet the requesting prerequisites of advanced businesses where each millimeter counts.
 |
 |
What Makes Our Slim Section Bearings Special?
Our lean area orientation stand out through their consistent cross-section plan logic. This building approach permits you to accomplish critical space reserve funds without compromising on execution. You'll discover these heading especially important when managing with tight spiral and pivotal space constraints.
The key advantage lies in the optimized geometry. Whereas a standard bearing might require considerable mounting space, our thin profile orientation diminish this prerequisite by up to 50% or more. This space effectiveness deciphers specifically into lighter, more compact plans for your hardware.
Product Specifications and Options
We offer four distinct structural configurations to match your specific needs:
Deep Groove Ball Bearings: Perfect for general-purpose applications requiring smooth rotation
Four-Point Contact Ball Bearings: Ideal when you need to handle combined radial and axial loads
Crossed Roller Bearings: Excellent for high rigidity requirements
Angular Contact Ball Bearings: Best suited for applications with predominantly axial loads
Size Range
- Inner Bore Diameter: 50mm to over 2000mm
- Cross-Section Height: 20mm to 100mm
Materials
- Ring Material: High-strength 50Mn or 42CrMo alloy steel
- Rolling Elements: Precision GCr15 bearing steel balls
- Seals: Oil-resistant NBR rubber seals
Key Industries and Applications
Your industry likely faces similar challenges - reducing weight, saving space, and maintaining precision. Our products excel in:
- Industrial Robotics: Enable precise joint movements in compact robotic arms
- Medical Equipment: Support critical functions in space-constrained diagnostic devices
- Aerospace Applications: Provide reliable operation while minimizing aircraft weight
- Precision Instruments: Deliver smooth rotation in sensitive measuring equipment
- New Energy Systems: Support wind turbine and solar tracking mechanisms
- Automation Equipment: Enable precise positioning in manufacturing systems
Quality You Can Trust
Our ISO9001 certification ensures consistent quality in every bearing we manufacture. Each Slim Section Bearings undergoes rigorous testing using coordinate measuring machines and vibration testers. We maintain precision grades from P0 to P4, allowing you to select the exact tolerance level your application demands.
With over 30 years of bearing expertise and a dedicated R&D team of 50+ engineers, we understand the critical nature of your applications. Our products comply with international standards including DIN, ISO, and GB specifications.
Custom Solutions for Unique Challenges
Every application presents unique challenges. Our engineering team provides comprehensive support from initial consultation through installation guidance. We offer custom bearing solutions when standard configurations don't meet your specific requirements.
Whether you need special materials, modified geometries, or specific performance characteristics, our flexible manufacturing capabilities can accommodate your needs.
Global Reach, Local Support
Our bearings currently serve customers across 50+ countries, from the United States and Germany to Australia and Malaysia. This global presence demonstrates the reliability and performance of our products across diverse applications and environments.
 |
 |
Frequently Asked Questions
Q: What's the main difference between products and standard bearings?
A: The primary difference is the cross-sectional thickness. Slim bearings maintain the same bore and outer diameter as standard bearings but with significantly reduced width, typically 30-50% thinner.
Q: Can products handle the same loads as standard bearings?
A: While load capacity may be somewhat reduced due to fewer rolling elements, our engineering design optimizes load distribution to maintain excellent performance for most applications.
Q: What precision grades are available?
A: We offer four precision grades: P0, P6, P5, and P4, with P4 being the highest precision level available.
Q: Do you provide installation support?
A: Yes, our engineering team provides comprehensive installation guidance and technical support throughout your project implementation.
Q: What's the typical lead time for custom bearings?
A: Lead times vary based on complexity and quantity. Contact us with your specific requirements for accurate delivery estimates.
 |
 |
Contact Us
Ready to explore how Slim Section Bearings can optimize your next project? Contact our engineering team at mia@hgb-bearing.com for technical consultation and custom solutions.
